Open Mouth Bagging Machine

GW-650 Fully Automatic Bagging System

GW-650 Fully Automatic Bagging System

Our GW is characterized by its great versatility, as it can work with gusseted, paper, coated paper and aluminum bags in a range of sizes, from 5 to 50 kg. This is because the various system components are self-adjusting in order to ensure optimum filling and perfect closing.



  • Brand:

    GAOGE
  • Warranty:

    2 Years
  • Certification:

    ISO CE
  • Port:

    Ningbo/Shanghai/Guangzhou
  • Packaging Details:

    Wooden Case
  • Machine Features

  • Specifications

  • Bag Shape

GW is GAOGE's fully automatic bagging system, up to 1000 bags/hour, designed specifically to fill and close medium open-mouth and gusseted bags.

Its particularly compactsize means that the machine can be installed in any existing production area.


Automatic bagging machine for open mouth bags without gusset, ideal for packaging granular products in a wide range of formats.

The GW bagging machine is designed to fill and close pre-formed bags easily and reliably. Ideal for medium and high production, this bagging machine adapts to the most varied market requirements of any sector.

The possibility of coupling any weighing or closing system makes GW the perfect solution for a wide range of granular products.


Feature:

* The automatic packaging machine can pack granular and powder materials into premade open mouth bags automatically, It can realize automatic bag feeding, bag opening, bag loading, products filling, bag sealing and others.

*The packed bag is well sealed, suitable for packing powder and granule, like feed, pet food, seed, rice, salt, fertilizer, etc.

*Friendly human-machine interface (HMI), it can providing complete fault diagnosis and solution, and quick switching of working modes for packing different characteristics materials.

* Controlled by the color touch screen(Siemens), and has real-time online detection function, which is convenient for different users

* Stable and reliable running, convenient maintenance

* Compact design ideal for restricted packaging rooms

* Individual bag pick-up and opening
* Empty bag (with or without gusset) transfer to filling mouth
* Bag hermetic fastening on filling mouth
* Bag filling (product discharge from scale or dozer) and vibrating
* Closing system: Thermo-sealing and/or multiple sewing, fold and glued etc.



Options
All common types of bag closing devices
Product de-aeration
Remote control panel
Bag turning
Closed bag ‘push off’ (top or bottom first)
Full stainless steel design




Model

GW-650

Applicable materials

granulargood liquidity)

Weighing range

5 to 50kg (10lb to 110lb)

Bag Matirical

Woven bag, kraft paper bag, PE bag

Bag Type

One line pocket, M side pocket

Speed

3 to 16 bags/min

Ambient temp

 -10°C to +45°C

Electrical

380V/50Hz, 3phase or customized per specification

Power

3KW

Air Pressure & Consumption

0.7Mpa, 0.6 M3min

Bag size(mm)

L 900-1100mm x W 550-650mm

Packing weight(kg)

40-50kg/bag
