The GW bagging machine is designed to fill and close pre-formed bags easily and reliably. Developed for medium and high production. It is the perfect solution for packaging Laundry Detergent Powder and similar products.
Brand:
GAOGEWarranty:
2 YearsCertification:
ISO CEPort:
Ningbo/Shanghai/GuangzhouPackaging Details:
Wooden Case
The GW bagging machine is designed to fill and close pre-formed bags easily and reliably. Developed for medium and high production. It is the perfect solution for packaging Laundry Detergent Powder and similar products.
Thanks to the presence of a double vibration/compacting station, which allows excess air to be eliminated, the GW can reach high production and quality levels.
Its single-piece structure and "step-by-step" handling of the products, allow any type of bag, with or without gusset, to be treated with maximum precision and efficiency. Transfer speed is guaranteed by servo-assisted movement with brushless motors.
* The automatic packaging machine can pack
granular and powder materials into premade open mouth bags automatically, It
can realize automatic bag feeding, bag opening, bag loading, products filling, bag
sealing and others.
*The packed bag is well sealed, suitable
for packing powder and granule, like feed, pet food, seed, rice, salt, fertilizer,
etc.
*Friendly human-machine interface (HMI), it
can providing complete fault diagnosis and solution, and quick switching of
working modes for packing different characteristics materials.
* Controlled by the color touch screen(Siemens),
and has real-time online detection function, which is convenient for different
users
* Stable and reliable running, convenient
maintenance
* Compact design ideal for restricted
packaging rooms
* Individual bag pick-up and opening
* Empty bag (with or without gusset) transfer to filling mouth
* Bag hermetic fastening on filling mouth
* Bag filling (product discharge from scale or dozer) and vibrating
* Closing system: Thermo-sealing and/or multiple sewing, fold and glued etc.
Options：
All common types of bag closing devices
Product de-aeration
Remote control panel
Bag turning
Closed bag ‘push off’ (top or bottom first)
Full stainless steel design
|
Model |
GW-550 |
|
Applicable materials |
granular（good liquidity) |
|
Weighing range |
5 to 50kg (10lb to 110lb) |
|
Bag Matirical |
Woven bag, kraft paper bag, PE bag |
|
Bag Type |
One line pocket, M side pocket |
|
Speed |
3 to 16 bags/min |
|
Ambient temp |
-10°C to +45°C |
|
Electrical |
380V/50Hz, 3phase or customized per specification |
|
Power |
3KW |
|
Air Pressure & Consumption |
0.7Mpa, 0.6 M3／min |
|
Bag size(mm) |
L800-1000 x W450-550mm |
|
Packing weight(kg) |
25-30kg/bag |
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Manual Bagging Equipment with electronic gross weighing system to meet international standards and provide high accuracy and reliability. The simple construction and sturdy design ensure safe and accurate operation.
Automatic bagging machines for open-mouthed bags. Ideal for packaging powdered products, fluidified and non in a wide range of formats.
Fish feeds dosing, weighing, bagging, packaging, palletizing machines from GaoGepak are accurate, fast and reliable.
The automated system illustrated below is an example of a complete line built with our salt bagging and packaging equipment. This line is equipped with a net weigh scale, an GW bagger, a conventional bag palletizer, and a stretch wrapper. No matter the scope of your project, GAOGE manufactures salt packaging equipment for small- and large-scale productions.
The automated system illustrated below is an example of a complete line built with our feed bagging and packaging solutions. This line is equipped with a net weigh scale, an GW bagger, a conventional bag palletizer and a stretch wrapper. No matter the scope of your project, GAOGE manufactures feed packaging equipment for small- and large-scale productions.
Open mouth bag fillers are very simple, fast filling and easy filling of both food grade and non-food grade materials. They are well suited for both manual and automated applications. Open mouth filling systems are ideal for hard to handle materials or products that are dry, free flowing and minimally dusty ranging from landscaping materials, feed, seed & fertilizer to food products.
Coffee Weighing machines, Bagging machines, Packaging machines, Palletisers and Wrappers for coffee The packaging of coffee (granules, soluble or beans) is one of the most important phases in its production process. Good packaging guarantees maximum yield in terms of quality and aroma.
This equipment is adapted for Food: Flour, Salt, Sugar, Rice, Grain, Spices.
